In this tutorial I am going to explain what are Kubernetes Replication Controllers and Replica Sets and will demonstrate how they work within a Kubernetes cluster.
There are two main types of Replications in Kubernetes -> ReplicaSets and Replication Controller. But before even starting exploring these concepts the first question in my mind arises is why I need the replication at first place? So, Lets start digging deeper and understand the reason.
Why we need replication?
A container or pod may crash because of multiple reasons. The main purpose of using Replication is Reliability, Load Balancing, and Scaling. It ensures that the pre-defined pods always exists.
To understand this in an easier manner lets take an example ->
Lets assume we are running our application on a single pod. What if for some reason our application crashes and the pod fails. Users will no longer be able to access our application.
To prevent users from losing access to our application we would like to have more than one instances of our application running at the same time. That way if one pod fails we still have our application running on the other one. The replication controller helps us run multiple instances of a single pod in the Kubernetes cluster. Thus providing high availability.
So does that mean you can’t use a replication controller if you plan to have a single pod! No, You can use it. Even if you have a single pod the replication controller can help by automatically bringing up a new pod when the existing one fails. Thus the replication controller ensures that the specified number of pods are running at all times.
Another reason we need a replication controller is to create multiple pods to share the load across them. Simple scenario is if we have a single pod serving a set of users, when the number of users increase we deploy additional pod to balance the load across the two pods if the demand further increases and if we were to run out of resources on the first node we could deploy additional pods across the other nodes in the cluster.
The replication controller spans across multiple nodes in the cluster. It helps us balance the load across multiple pods on different nodes as well as scale our application when the demand increases.
It’s important to note that there are two similar terms replication controller and ReplicaSet
What is Replication Controller in Kubernetes ?
A Replication Controller ensures that a specified number of pod replicas are running at any given time. In other words, a Replication Controller makes sure that a pod or a homogeneous set of pods is always up and available.
What is ReplicaSet’s in Kubernetes ?
A ReplicaSet’s purpose is to maintain a stable set of replica Pods running at any given time. As such, it is often used to guarantee the availability of a specified number of identical Pods. The ReplicaSets are also known as next generation replication controller.
ReplicaSets checks whether the target pod is already managed by another controller as well (like a Deployment or another ReplicaSet).
Difference between Kubernetes Replication Controllers and Replica Sets
Replication Controller and Replica Set do almost the same thing. Both of them ensure that a specified number of pod replicas are running at any given time.
The difference comes with the usage of selectors to replicate pods. Replica Set use Set-Based selectors which gives more flexibility while replication controllers use Equity-Based selectors.
ReplicationController eg:
app = front-end
This will select all the resources with key equal to app and value equal to front-end as it supports Equity-Based selectors.
Three type of operators used in set based equality based selectors are –> = , == , !=. The first two represent equality (and are simply synonyms), while the latter represents inequality.
For example, if we provide the following selectors:
env = staging
tier != front-end
Here, we’ll select all resources with key equal to env and value equal to staging. The latter selects all resources with key equal to tier and value distinct from front-end, and all resources with no labels with the tier key.
ReplicaSet eg:
tier in (front-end, back-end)
This will select all the resources with key equal to app and value equal to front-end or back-end as it supports Set-Based selectors.
Three type of operators used in set-based selectors are –> in , notin, exists(only the key identifier).
For example, if we provide the following selectors:
env in (prod, qa, dev, staging)
tier notin (front-end, back-end) webapp
Here, in the first selector will selects all resources with key equal to environment and value equal to production or qa or staging or dev.
The second example selects all resources with key equal to tier and values other than front-end and back-end, and all resources with no labels with the tier key. The third example selects all resources including a label with key webapp; no values are checked.
Creating a Replication Controller
Now I will demonstrate how we can create Replication Controller using the yaml manifest file.
apiVersion: v1
kind: ReplicationController
metadata:
name: fosstechnix-httpd-rc-demo
spec:
replicas: 3
selector:
app: httpd
tier: qa
template:
metadata:
name: httpd
labels:
app: httpd
tier: qa
spec:
containers:
- name: httpd-container
image: httpd
imagePullPolicy: IfNotPresent
ports:
- containerPort: 80Above is the manifest file which will create the defined Replication Controller and the Pods that it manages when submitted to Kubernetes cluster.
[email protected]:~/replication# kubectl apply -f rc.yml
replicationcontroller/fosstechnix-httpd-rc-demo createdVerify the above resource creation:
[email protected]:~/replication# kubectl get replicationcontrollers fosstechnix-httpd-rc-demo
NAME DESIRED CURRENT READY AGE
fosstechnix-httpd-rc-demo 3 3 3 12sDescribe the Replication Controller we created
[email protected]:~/replication# kubectl describe replicationcontrollers fosstechnix-httpd-rc-demo
Name: fosstechnix-httpd-rc-demo
Namespace: default
Selector: app=httpd,tier=qa
Labels: app=httpd
tier=qa
Annotations: <none>
Replicas: 3 current / 3 desired
Pods Status: 3 Running / 0 Waiting / 0 Succeeded / 0 Failed
Pod Template:
Labels: app=httpd
tier=qa
Containers:
httpd-container:
Image: httpd
Port: 80/TCP
Host Port: 0/TCP
Environment: <none>
Mounts: <none>
Volumes: <none>
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal SuccessfulCreate 24s replication-controller Created pod: fosstechnix-httpd-rc-demo-twrd2
Normal SuccessfulCreate 24s replication-controller Created pod: fosstechnix-httpd-rc-demo-xdnwd
Normal SuccessfulCreate 24s replication-controller Created pod: fosstechnix-httpd-rc-demo-d9v24Verify the pods running:
[email protected]:~/replication# kubectl get pods
NAME READY STATUS RESTARTS AGE
fosstechnix-httpd-rc-demo-d9v24 1/1 Running 0 40s
fosstechnix-httpd-rc-demo-twrd2 1/1 Running 0 40s
fosstechnix-httpd-rc-demo-xdnwd 1/1 Running 0 40sLet’s verify the Replication Controller functionality by deleting a running pod controlled by replication controller manually and the replication controller will automatically spawn a new pod to meet the desired state. Here’s an example:
[email protected]:~/replication# kubectl delete pod fosstechnix-httpd-rc-demo-d9v24
pod "fosstechnix-httpd-rc-demo-d9v24" deletedVerify the status of running pods :
[email protected]:~/replication# kubectl get pods
NAME READY STATUS RESTARTS AGE
fosstechnix-httpd-rc-demo-brfj7 1/1 Running 0 11s
fosstechnix-httpd-rc-demo-twrd2 1/1 Running 0 65s
fosstechnix-httpd-rc-demo-xdnwd 1/1 Running 0 65sThe new pod (fosstechnix-httpd-rc-demo-brfj7) has been created with a different pod name to maintain the replica count we have specified.
Within the specification file if we didn’t put the selector, the replication controller will automatically configure it with the labels of pod, as the pod labels must match the replication controller selectors, otherwise the pods will move out of the scope of replication controller.
Scaling up a Replication Controller
[email protected]:~/replication# kubectl scale replicationcontroller --replicas=5 fosstechnix-httpd-rc-demo
replicationcontroller/fosstechnix-httpd-rc-demo scaledVerify the pods running now:
[email protected]:~/replication# kubectl get pods
NAME READY STATUS RESTARTS AGE
fosstechnix-httpd-rc-demo-brfj7 1/1 Running 0 64s
fosstechnix-httpd-rc-demo-kbv8f 1/1 Running 0 20s
fosstechnix-httpd-rc-demo-s4t42 1/1 Running 0 20s
fosstechnix-httpd-rc-demo-twrd2 1/1 Running 0 118s
fosstechnix-httpd-rc-demo-xdnwd 1/1 Running 0 118sTwo new pods have been added.
Deleting Replication Controller
[email protected]:~/replication# kubectl delete replicationcontrollers fosstechnix-httpd-rc-demo
replicationcontroller "fosstechnix-httpd-rc-demo" deletedCreating a ReplicaSet
Time to demonstrate the creation of Replicaset using the yaml manifest file. To be able to create new pods if necessary, the ReplicaSet definition includes a template part containing the definition for new pods.
[email protected]:~/replication# cat rs.yml
apiVersion: apps/v1
kind: ReplicaSet
metadata:
name: fosstechnix-httpd-rs-demo
spec:
replicas: 3
selector:
matchLabels:
env: qa
matchExpressions:
- { key: tier, operator: In, values: [front-end] }
template:
metadata:
name: httpd
labels:
env: qa
tier: front-end
spec:
containers:
- name: httpd-container
image: httpd
imagePullPolicy: IfNotPresent
ports:
- containerPort: 80Above is the manifest file which will create the defined ReplicaSet and the Pods that it manages when submitted to Kubernetes cluster.
NOTE: Make sure you do not use a label that is already in use by another controller. Otherwise, another ReplicaSet or Controller may acquire the pod(s) first. Also notice that the labels defined in the pod template cannot be different than those defined in the matchLabels part.
[email protected]:~/replication# kubectl apply -f rs.yml
replicaset.apps/fosstechnix-httpd-rs-demo createdDescribe the ReplicaSet we created
[email protected]:~/replication# kubectl describe replicasets.apps fosstechnix-httpd-rs-demo
Name: fosstechnix-httpd-rs-demo
Namespace: default
Selector: env=qa,tier in (front-end)
Labels: <none>
Annotations: <none>
Replicas: 3 current / 3 desired
Pods Status: 3 Running / 0 Waiting / 0 Succeeded / 0 Failed
Pod Template:
Labels: env=qa
tier=front-end
Containers:
httpd-container:
Image: httpd
Port: 80/TCP
Host Port: 0/TCP
Environment: <none>
Mounts: <none>
Volumes: <none>
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal SuccessfulCreate 98s replicaset-controller Created pod: fosstechnix-httpd-rs-demo-qnjfk
Normal SuccessfulCreate 98s replicaset-controller Created pod: fosstechnix-httpd-rs-demo-d266w
Normal SuccessfulCreate 98s replicaset-controller Created pod: fosstechnix-httpd-rs-demo-29chzVerify the running pods:
[email protected]:~/replication# kubectl get pods
NAME READY STATUS RESTARTS AGE
fosstechnix-httpd-rs-demo-29chz 1/1 Running 0 2m
fosstechnix-httpd-rs-demo-d266w 1/1 Running 0 2m
fosstechnix-httpd-rs-demo-qnjfk 1/1 Running 0 2mScaling up a ReplicaSet
[email protected]:~/replication# kubectl scale replicaset --replicas=5 fosstechnix-httpd-rs-demo
replicaset.apps/fosstechnix-httpd-rs-demo scaledVerify the running pods:
[email protected]:~/replication# kubectl get pods
NAME READY STATUS RESTARTS AGE
fosstechnix-httpd-rs-demo-29chz 1/1 Running 0 4m11s
fosstechnix-httpd-rs-demo-6xfkj 1/1 Running 0 24s
fosstechnix-httpd-rs-demo-d266w 1/1 Running 0 4m11s
fosstechnix-httpd-rs-demo-gjxb7 1/1 Running 0 24s
fosstechnix-httpd-rs-demo-qnjfk 1/1 Running 0 4m11sConfigure Auto Scaling on a ReplicaSet
We can configure autoscaling for ReplicaSets to scale upto the maximum number of pods defined according to the CPU load that the node is having.
Run the following command to enable autoscaling for our ReplicaSet :
[email protected]:~/replication# kubectl autoscale replicaset --max=5 fosstechnix-httpd-rs-demo
horizontalpodautoscaler.autoscaling/fosstechnix-httpd-rs-demo autoscaledFind out the the owner of running pods
In your production environment where you may have thousands of pods running, you may want to verify that a particular pod is actually managed by this ReplicaSet or not. By querying the pod, you can get this info:
[email protected]:~/replication# kubectl get pods fosstechnix-httpd-rs-demo-29chz -o yaml | grep -A 5 owner
ownerReferences:
- apiVersion: apps/v1
blockOwnerDeletion: true
controller: true
kind: ReplicaSet
name: fosstechnix-httpd-rs-demoDeleting a ReplicaSet
A ReplicaSet can be deleted by issuing a kubectl command like the following:
[email protected]:~/replication# kubectl delete replicasets.apps fosstechnix-httpd-rs-demo
replicaset.apps "fosstechnix-httpd-rs-demo" deletedThe above command will delete the ReplicaSet and all the managed pods.
But lets say you just want to delete the ReplicaSet resource, not the pods it manages. Run the following command:
[email protected]:~/replication# kubectl delete replicasets.apps fosstechnix-httpd-rs-demo --cascade=false
replicaset.apps "fosstechnix-httpd-rs-demo" deletedVerify if the pods are still running or not:
[email protected]:~/replication# kubectl get pods
NAME READY STATUS RESTARTS AGE
fosstechnix-httpd-rs-demo-9qzh7 1/1 Running 0 6m5s
fosstechnix-httpd-rs-demo-c7rh6 1/1 Running 0 6m5s
fosstechnix-httpd-rs-demo-gcd45 1/1 Running 0 6m5sVerify if the ReplicaSet is deleted:
[email protected]:~/replication# kubectl get replicasets.apps
No resources found in default namespace.NOTE:
One should never create a bare pod with a label that matches the selector of a ReplicaSet controller unless its template matches the pod definition. Because once you create it the ReplicaSet controller will automatically adopt it. And if the newly created bare pod’s specifications are different then the controller is programmed to use (for eg. container image is different) then you will have consequences of losing data.
The recommended method is to always use a controller like a ReplicaSet or a Deployment to create and maintain your pods.
That’s all for this particular topic.
Hope you like the tutorial. Please let us know your feedback in the response section.
